Jodell ELS Series

The ELS series is a miniature electric table type cylinder independently developed and manufactured by Jodell,with high energy density, heavy load capacity, and compact design. It can be applied to various application scenarios to complete complex tasks, such as pick and place, arrangement, and handling.

1. Engineering Breakthroughs

Nanometer Precision: ±0.005mm repeatability with optical encoder option
Granite Base: Zero thermal deformation for metrology applications

2. Smart Features

Collision Detection: Auto-reverse upon overload
Life Prediction: Real-time ball screw wear monitoring

3. Industry 4.0 Ready

PLCopen Function Blocks: Simplify programming on CODESYS platforms
Digital Twin Support: Import 3D model into NVIDIA Omniverse

model	ELS-SW	ELS-SW	ELS-SW	ELS-30	ELS-30	ELS-30	ELS-50	ELS-50	ELS-50
Total Travel	30，50mm	30，50mm	30，50mm	30mm	30mm	30mm	50mm	50mm	50mm
Lead of lead screw mm	2mm	4mm	6mm	2mm	4mm	6mm	2mm	4mm	6mm
Rated thrust N	100N	50N	30N	100N	50N	30N	100N	50N	30N
Minimum thrust N	30N	15N	9N	30N	15N	9N	30N	15N	9N
Maximum speed mm/s	100mm/s	200mm/s	300mm/s	100mm/s	200mm/s	300mm/s	100mm/s	200mm/s	300mm/s
Maximum acceleration G	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3	0.3
Maximum Portable Weight – Horizontal kg	6kg	3kg	2kg	6kg	3kg	2kg	6kg	3kg	2kg
Maximum Portable Weight – Vertical kg	1.5kg	0.75kg	0.5kg	1.5kg	0.75kg	0.5kg	1.5kg	0.75kg	0.5kg
Position repetition accuracy mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm	±0.02mm
Body width mm	36mm	36mm	36mm	45mm	45mm	45mm	45mm	45mm	45mm
Function Description	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode	Position mode/Push mode
Communication protocol	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional	Built in: Modbus RTU (RS485) Digital I/O, IO link optional
Recommended usage environment	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH	0~40°C，＜85% RH
Interface cable outlet method	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet	Tail outlet/side outlet
Walking lifespan	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km	50 million round trips/5000 km
Rated voltage V	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%	DC 24V ±10%
Rated current A	1.5A	1.5A	1.5A	1.5A	1.5A	1.5A	1.5A	1.5A	1.5A
Peak current A	3A	3A	3A	3A	3A	3A	3A	3A	3A
Rated power W	20W	20W	20W	20W	20W	20W	20W	20W	20W
Motor type	DC servo motor	DC servo motor	DC servo motor	DC servo motor	DC servo motor	DC servo motor	DC servo motor	DC servo motor	DC servo motor
Static allowable load torque Mx	32N·m	32N·m	32N·m	32N·m	32N·m	32N·m	32N·m	32N·m	32N·m
Static allowable load torque My	20N·m	20N·m	20N·m	20N·m	20N·m	20N·m	20N·m	20N·m	20N·m
Static allowable load torque Mz	23N·m	23N·m	23N·m	23N·m	23N·m	23N·m	23N·m	23N·m	23N·m
Dynamic allowable load torque Mx	12.5N·m	12.5N·m	12.5N·m	12.5N·m	12.5N·m	12.5N·m	12.5N·m	12.5N·m	12.5N·m
Dynamic allowable load torque My	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m
Dynamic allowable load torque Mz	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m	10N·m
Protection level	IP40	IP40	IP40	IP40	IP40	IP40	IP40	IP40	IP40
Compliant with international standards	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS	CE，FCC，RoHS
Installation method	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation	Horizontal installation, vertical installation, side standing installation, suspended ceiling installation
