5th Axis CNC Rotary Table (Trunnion Type)

The Trunnion 5-Axis CNC Rotary Table combines a 4th axis rotary table with a tilting axis to create a high-precision dual-axis system, transforming a standard 3-axis machining center into a 5-axis machining solution. This setup enables flexible angular positioning and multi-face machining for complex and irregular workpieces, greatly improving productivity and precision.

Key Features

1. High-Precision Dual-Axis Design
   • Worm gear drive with high-resolution encoders ensures accurate rotation and tilt control.
   • Rigid trunnion structure guarantees stability and cutting accuracy during 5-axis simultaneous machining.
2. Flexible Multi-Angle Machining
   • Tilting range up to ±120° or more, ideal for complex parts and curved surfaces.
   • Minimizes workpiece repositioning and reduces setup time.
3. Servo-Driven & Intelligent Control
   • Equipped with servo motors, compatible with Fanuc, Mitsubishi, Siemens, and other major CNC systems.
   • Supports indexing, simultaneous 5-axis, and full closed-loop control modes.
4. Strong Clamping & Load Capacity
   • Pneumatic or hydraulic clamping ensures workpiece stability under high-speed cutting.
   • Suitable for aerospace, automotive, medical, and precision mold applications.

Technical Specifications

Custom sizes, tilt ranges, and servo interfaces are available upon request.

Applications

Upgrades a 3-axis machining center to a full 5-axis solution

Multi-face and complex surface machining for aerospace components

Precision manufacturing of engine parts, turbine blades, and medical devices

High-speed multi-face milling and drilling in mold industries

…
